1
Imported parts, electrical and
pneumatic components.
2
Manually adjust the height and the width for
different size of cartons;
3
Top and bottom belts driven;
sides sealing.
4
Cutter Safety system to prevent
hands form stabbed by the cutter.
5
Independent button switch
design ensures safety and stability.
6
Both steel and stainless steel
types.
7
Universal type, fit for all
kinds of cartons sealing.
8
Manual folding - Manual Input -
automatic sealing - automatic output.
9
Adjustment time is 5 minutes
per time for replace the carton.
10
It can be used as a stand-alone
machine or in combination with an assembly line.
Standard components:
1 Motor: Taiwan GPG
2 Switch: Taiwan Sherndec independent
switch
3 Brake removable casters
4 Stainless steel conveyor
Model |
WWP-950B |
Conveyor speed |
17.5m/min |
Packing size |
L:150-∞mm*W:100-400mm*H:250-400mm |
Max. load limit |
30kg |
Power supply |
110V, 220-240V, 50/60Hz, 1Phase |
Power |
240W |
Table height |
580-680mm (Adjustable) |
Adhesive tape width |
50-70mm |
Machine dimension |
L1920×W1010×H1350mm |
Machine weight |
130kg |
