Main performance and structure features

1. Dual frequency conversion control, Bag length can be set and cut in one step, saving time and film.

2. Interface features easy and quick setting and operation.

3. Self failure diagnosis, clear failure display.

4. High sensitivity photoelectric eye color tracing, numerical input of cutting/sealing position for extra accuracy.

5. Temperature independent PID control, more suitable for packaging different materials.

6. Positioned stop function, without sticking knife or wasting film.

7. Simple driving system, reliable working, convenient maintenance.

8. All control is realized through software, easy for function adjusting and technical upgrade.

Application

Packaging various kinds of regular objects like biscuits, pies, chocolates, bread, instant noodles, moon-cakes, drugs, daily appliances, industrial parts, paper boxes, plates, etc.

Optional device

1. Code applying machine

2. line sealing wheel

3. Moire terminal sealing mould

4. Extra big screen

Specification

Film width  Max. 320mm

Bag length 65-190 mm or 120-280mm

Bag width 50-160mm

Product height Max.45mm

Film roll diameter Max. 320mm

Packaging rate 40-230 bag/min

Power 220V,50/60HZ,2.6KVA

Machine size (L)3770X(W)720X(H)1450

Machine quality  900kg

Delivery time

In stock or 20 days
